settings/src/gtkSettingItemTextEntry.c File Reference

setup application - setup item containing one text entry field More...

#include <gtk/gtk.h>
#include <liberdm/display.h>
#include <libergtk/ergtk.h>
#include "setupLog.h"
#include "displayStatus.h"
#include "gtkSettingItem.h"
#include "gtkSettingItemTextEntry.h"

Go to the source code of this file.

Defines

#define LOGPRINTF   ST_LOGPRINTF

Enumerations

enum  { ENTER_SELECTED, LAST_SIGNAL }

Functions

static void gtk_settingitem_textentry_class_init (GtkSettingItemTextEntryClass *klass)
static void gtk_settingitem_textentry_init (GtkSettingItemTextEntry *item)
static gboolean on_focus_out (GtkWidget *widget, GdkEventFocus *event, gpointer data)
static void on_validate (GtkSettingItemTextEntry *item)
static gboolean on_entry_button_press (GtkWidget *widget, GdkEventButton *event, gpointer data)
static void on_changed_stable (GtkEditable *widget, gpointer data)
GtkWidget * gtk_settingitem_textentry_new ()
GType gtk_settingitem_textentry_get_type (void)
void gtk_settingitem_textentry_setlabel (GtkSettingItemTextEntry *item, const gchar *text)
void gtk_settingitem_textentry_setinfo (GtkSettingItemTextEntry *item, const gchar *text)
void gtk_settingitem_textentry_settext (GtkSettingItemTextEntry *item, const gchar *text)
const gchar * gtk_settingitem_textentry_gettext (GtkSettingItemTextEntry *item)
void gtk_settingitem_textentry_setvisibility (GtkSettingItemTextEntry *item, gboolean visible)
void gtk_settingitem_textentry_setentrywidth (GtkSettingItemTextEntry *item, guint width)
void gtk_settingitem_textentry_callback_on_changed (GtkSettingItemTextEntry *item, on_textentry_changed_t *callback)
void gtk_settingitem_textentry_callback_on_button_press (GtkSettingItemTextEntry *item, on_textentry_button_press_t *callback)
void gtk_settingitem_textentry_callback_on_validate (GtkSettingItemTextEntry *item, on_textentry_validate_t *callback)
void gtk_settingitem_textentry_grabfocus (GtkSettingItemTextEntry *item)

Variables

static gint settingitem_textentry_signals [LAST_SIGNAL] = { 0 }

Detailed Description

setup application - setup item containing one text entry field

Copyright (C) 2005-2008 iRex Technologies B.V. All rights reserved.

<File description>="">

Definition in file gtkSettingItemTextEntry.c.

Define Documentation

#define LOGPRINTF   ST_LOGPRINTF

Definition at line 41 of file gtkSettingItemTextEntry.c.

Enumeration Type Documentation

anonymous enum

Enumerator:
ENTER_SELECTED
LAST_SIGNAL

Definition at line 43 of file gtkSettingItemTextEntry.c.

00044 {
00045     ENTER_SELECTED,             // signals emitted when the user selects enter on the keyboard
00046     LAST_SIGNAL,
00047 };

Function Documentation

void gtk_settingitem_textentry_callback_on_button_press ( GtkSettingItemTextEntry *  item,
on_textentry_button_press_t *  callback
)

Definition at line 234 of file gtkSettingItemTextEntry.c.

00235 {
00236     item->callback_on_button_press = callback;
00237 }

void gtk_settingitem_textentry_callback_on_changed ( GtkSettingItemTextEntry *  item,
on_textentry_changed_t *  callback
)

Definition at line 229 of file gtkSettingItemTextEntry.c.

00230 {
00231     item->callback_on_changed = callback;
00232 }

void gtk_settingitem_textentry_callback_on_validate ( GtkSettingItemTextEntry *  item,
on_textentry_validate_t *  callback
)

Definition at line 239 of file gtkSettingItemTextEntry.c.

00240 {
00241     item->callback_on_validate = callback;
00242 }

static void gtk_settingitem_textentry_class_init ( GtkSettingItemTextEntryClass *  klass  )  [static]

Definition at line 99 of file gtkSettingItemTextEntry.c.

00100 {
00101     GtkObjectClass *object_class;
00102
00103     object_class = (GtkObjectClass *) klass;
00104
00105     // event to notify page update
00106
00107     settingitem_textentry_signals[ENTER_SELECTED] =
00108         g_signal_new("settingitem_textentry_enter",
00109                      G_OBJECT_CLASS_TYPE(object_class),
00110                      G_SIGNAL_RUN_LAST,
00111                      G_STRUCT_OFFSET(GtkSettingItemTextEntryClass, settingitem_textentry_enter),
00112                      NULL, NULL, gtk_marshal_VOID__STRING, G_TYPE_NONE, 1, G_TYPE_CHAR);
00113 }

GType gtk_settingitem_textentry_get_type ( void   )

Definition at line 75 of file gtkSettingItemTextEntry.c.

00076 {
00077     static GType settingitem_textentry_type = 0;
00078
00079     if (!settingitem_textentry_type)
00080     {
00081         static const GTypeInfo settingitem_textentry_info = {
00082             sizeof(GtkSettingItemTextEntryClass),
00083             NULL,               /* base_init */
00084             NULL,               /* base_finalize */
00085             (GClassInitFunc) gtk_settingitem_textentry_class_init,
00086             NULL,               /* class_finalize */
00087             NULL,               /* class_data */
00088             sizeof(GtkSettingItemTextEntry),
00089             0,                  /* n_preallocs */
00090             (GInstanceInitFunc) gtk_settingitem_textentry_init,
00091         };
00092
00093         settingitem_textentry_type = g_type_register_static(GTK_TYPE_EVENT_BOX, "SettingItemTextEntry", &settingitem_textentry_info, 0);
00094     }
00095     return settingitem_textentry_type;
00096 }

Here is the call graph for this function:

const gchar* gtk_settingitem_textentry_gettext ( GtkSettingItemTextEntry *  item  )

Definition at line 214 of file gtkSettingItemTextEntry.c.

00215 {
00216     return gtk_entry_get_text(GTK_ENTRY(item->entry));
00217 }

void gtk_settingitem_textentry_grabfocus ( GtkSettingItemTextEntry *  item  )

Definition at line 244 of file gtkSettingItemTextEntry.c.

00245 {
00246     ST_LOGPRINTF("entry");
00247     gtk_widget_grab_focus(item->entry);
00248 }

static void gtk_settingitem_textentry_init ( GtkSettingItemTextEntry *  item  )  [static]

Definition at line 128 of file gtkSettingItemTextEntry.c.

00129 {
00130     GtkWidget *item_background;
00131     GtkWidget *alignment;
00132     GtkWidget *vbox;
00133     GtkWidget *hbox;
00134     GtkWidget *widget;
00135
00136     gtk_widget_set_size_request(GTK_WIDGET(item), SETTINGITEMTEXT_REQ_WIDTH, SETTINGITEMTEXT_REQ_HEIGHT);
00137
00138     // item_background
00139     item_background = gtk_event_box_new();
00140     gtk_widget_set_name(GTK_WIDGET(item_background), "settingitem_te_background");
00141     gtk_container_add(GTK_CONTAINER(item), item_background);
00142
00143     // alignment
00144     alignment = gtk_alignment_new(0.0, 0.0, 0.0, 0.0);
00145     gtk_alignment_set_padding(GTK_ALIGNMENT(alignment),
00146                               SETTINGITEMTEXT_BORDER_TOP,
00147                               SETTINGITEMTEXT_BORDER_BOTTOM,
00148                               SETTINGITEMTEXT_BORDER_LEFT,
00149                               SETTINGITEMTEXT_BORDER_RIGHT );
00150     gtk_container_add(GTK_CONTAINER(item_background), alignment);
00151
00152     // vbox
00153     vbox = gtk_vbox_new(FALSE, 0);
00154     gtk_widget_set_size_request(vbox, -1, -1);
00155     gtk_container_add(GTK_CONTAINER(alignment), vbox);
00156
00157     // item->label
00158     widget = gtk_label_new("");
00159     gtk_widget_set_name(widget, "settingitem_te_label");
00160     gtk_widget_set_size_request(widget, SETTINGITEMTEXT_REQ_WIDTH, SETTINGITEMTEXT_LABEL_HEIGHT);
00161     gtk_misc_set_alignment(GTK_MISC(widget), 0.0, 0.6);
00162     gtk_box_pack_start(GTK_BOX(vbox), widget, FALSE, FALSE, 0);
00163     item->label = widget;
00164
00165     // hbox
00166     hbox = gtk_hbox_new(FALSE, SETTINGITEMTEXT_HBOX_SPACING);
00167     gtk_widget_set_size_request(hbox, -1, -1);
00168     gtk_box_pack_start(GTK_BOX(vbox), hbox, FALSE, FALSE, 0);
00169
00170     // item->entry
00171     widget = ergtk_entry_new();
00172     gtk_widget_set_size_request(widget, SETTINGITEMTEXT_ENTRY_WIDTH, SETTINGITEMTEXT_ENTRY_HEIGHT);
00173     gtk_box_pack_start(GTK_BOX(hbox), widget, FALSE, FALSE, 0);
00174     item->entry = widget;
00175     //     signal callbacks
00176     g_signal_connect_after( G_OBJECT(widget), "focus-out-event",    G_CALLBACK(on_focus_out),          item);
00177     g_signal_connect(       G_OBJECT(widget), "button-press-event", G_CALLBACK(on_entry_button_press), item);
00178     g_signal_connect_after( G_OBJECT(widget), "changed-stable",     G_CALLBACK(on_changed_stable),     item);
00179
00180     // item->entry_info
00181     widget = gtk_label_new("");
00182     gtk_widget_set_name(widget, "settingitem_te_label");
00183     gtk_widget_set_size_request(widget, -1, SETTINGITEMTEXT_LABEL_HEIGHT);
00184     gtk_misc_set_alignment(GTK_MISC(widget), 0.0, 0.5);
00185     gtk_box_pack_start(GTK_BOX(hbox), widget, FALSE, FALSE, 0);
00186     item->entry_info = widget;
00187
00188     // display
00189     gtk_widget_show_all(GTK_WIDGET(item));
00190
00191     // instance-private data
00192     item->callback_on_button_press = NULL;
00193     item->callback_on_changed      = NULL;
00194     item->callback_on_validate     = NULL;
00195 }

Here is the call graph for this function:

GtkWidget* gtk_settingitem_textentry_new ( void   )

Definition at line 65 of file gtkSettingItemTextEntry.c.

00066 {
00067     GtkSettingItemTextEntry *settingItem;
00068
00069     settingItem = (GtkSettingItemTextEntry *) g_object_new(GTK_SETTINGITEM_TEXTENTRY_TYPE, NULL);
00070
00071     return GTK_WIDGET(settingItem);
00072 }

void gtk_settingitem_textentry_setentrywidth ( GtkSettingItemTextEntry *  item,
guint  width
)

Definition at line 224 of file gtkSettingItemTextEntry.c.

00225 {
00226     gtk_widget_set_size_request(GTK_WIDGET(item->entry), width, SETTINGITEMTEXT_ENTRY_HEIGHT);
00227 }

void gtk_settingitem_textentry_setinfo ( GtkSettingItemTextEntry *  item,
const gchar *  text
)

Definition at line 203 of file gtkSettingItemTextEntry.c.

00204 {
00205     gtk_label_set_text(GTK_LABEL(item->entry_info), text);
00206 }

void gtk_settingitem_textentry_setlabel ( GtkSettingItemTextEntry *  item,
const gchar *  text
)

Definition at line 198 of file gtkSettingItemTextEntry.c.

00199 {
00200     gtk_label_set_text(GTK_LABEL(item->label), text);
00201 }

void gtk_settingitem_textentry_settext ( GtkSettingItemTextEntry *  item,
const gchar *  text
)

Definition at line 208 of file gtkSettingItemTextEntry.c.

00209 {
00210     gtk_entry_set_text(GTK_ENTRY(item->entry), text);
00211     on_validate(item);
00212 }

Here is the call graph for this function:

void gtk_settingitem_textentry_setvisibility ( GtkSettingItemTextEntry *  item,
gboolean  visible
)

Definition at line 219 of file gtkSettingItemTextEntry.c.

00220 {
00221     gtk_entry_set_visibility(GTK_ENTRY(item->entry), visible);
00222 }

static void on_changed_stable ( GtkEditable *  widget,
gpointer  data
) [static]

Definition at line 298 of file gtkSettingItemTextEntry.c.

00299 {
00300     LOGPRINTF("entry");
00301
00302     GtkSettingItemTextEntry* item = GTK_SETTINGITEM_TEXTENTRY(data);
00303     g_return_if_fail(item != NULL);
00304
00305     // report item text has changed
00306     if (item->callback_on_changed)
00307     {
00308         item->callback_on_changed( GTK_WIDGET(item),
00309                                    gtk_entry_get_text(GTK_ENTRY(item->entry)) );
00310     }
00311 }

static gboolean on_entry_button_press ( GtkWidget *  widget,
GdkEventButton *  event,
gpointer  data
) [static]

Definition at line 282 of file gtkSettingItemTextEntry.c.

00283 {
00284     LOGPRINTF("entry");
00285
00286     GtkSettingItemTextEntry* item = GTK_SETTINGITEM_TEXTENTRY(data);
00287     if (IS_GTK_SETTINGITEM_TEXTENTRY(item))
00288     {
00289         if (item->callback_on_button_press)
00290         {
00291             item->callback_on_button_press( GTK_WIDGET(item) );
00292         }
00293     }
00294
00295     return FALSE;  // continue with GTK signal handling
00296 }

static gboolean on_focus_out ( GtkWidget *  widget,
GdkEventFocus *  event,
gpointer  data
) [static]

Definition at line 251 of file gtkSettingItemTextEntry.c.

00252 {
00253     LOGPRINTF("entry");
00254
00255     // validate & fix content
00256     on_validate( GTK_SETTINGITEM_TEXTENTRY(data) );
00257
00258     return FALSE;
00259 }

Here is the call graph for this function:

static void on_validate ( GtkSettingItemTextEntry *  item  )  [static]

Definition at line 261 of file gtkSettingItemTextEntry.c.

00262 {
00263     LOGPRINTF("entry");
00264
00265     gchar* new_text = NULL;
00266
00267     // validate & fix content
00268     if (item->callback_on_validate)
00269     {
00270         item->callback_on_validate( GTK_WIDGET(item),
00271                                     gtk_entry_get_text(GTK_ENTRY(item->entry)),
00272                                     &new_text );
00273         if (new_text)
00274         {
00275             gtk_entry_set_text(GTK_ENTRY(item->entry), new_text);
00276             g_free(new_text);
00277             new_text = NULL;
00278         }
00279     }
00280 }

Variable Documentation

gint settingitem_textentry_signals[LAST_SIGNAL] = { 0 } [static]

Definition at line 49 of file gtkSettingItemTextEntry.c.

Generated on Sun Dec 14 17:16:59 2008 by  doxygen 1.5.6
